9 photos · dimensions diagram in the spec sheet below
Order #341-0318 · 20 in / 500 mm cleaning path · Ships same day from Columbus, OH
48-month terms via our financing partners · check your rate — no credit impact
Talk to an equipment expert before you buy — 1-800-USA-CLEAN, Mon–Fri 7a–7p CT
$350 flat freight to the lower 48 — liftgate and inside delivery included, 3–5 business days. Arrives assembled with batteries installed; you're scrubbing in under 30 minutes.
From the manufacturer spec sheet for order #341-0318 — the same data the live site buries in an off-site image-only PDF.
| Performance | |
|---|---|
| Cleaning path | 20 in500 mm |
| Theoretical coverage | up to 24,200 ft²/hrup to 2,250 m²/hr |
| Pad speed | 155 rpm |
| Pad pressure | 66 lbs30 kg |
| Squeegee width | 33 in830 mm |
| Run time per charge | up to 3.5 hrs |
| Tanks & dimensions | |
| Solution tank | 15 gal60 L |
| Recovery tank | 17 gal65 L |
| Dimensions (L × W × H) | 56 × 22 × 38 in1410 × 560 × 965 mm |
| Machine weight | 286 lbs130 kg |
| Power | |
| Power source | (2) 12V sealed AGM batteries |
| Brush motor | 24V 500W |
| Vacuum motor | 24V 500W |
| Drive system | Traction drive — powered forward/reverse |
| Charger | 24V 15Ah offboard (included) · order #341-0248 |
| Warranty & service | |
| Parts warranty | 5 years |
| Labor warranty | 2 years |
| Wear parts availability | Every SKU stocked in the USA — ships same day |
| Support | 1-800-USA-CLEAN · equipment experts, Mon–Fri 7a–7p CT |
X20BT values from the manufacturer spec sheet (341-0318). Comparison values for sibling models on this prototype are placeholders pending catalog data.
Every wear part for this machine, stocked in the USA and shipping same day. This is why you buy equipment from a parts company: no six-week overseas wait when a squeegee blade or vacuum motor goes.
No surprises: the machine, plus the wear parts it will actually consume. Prices are today's catalog prices for the exact SKUs above.
| Line item | Assumption | 5-year cost |
|---|---|---|
| X20BT machine | One-time · 5-yr parts / 2-yr labor warranty | $4,295 |
| Floor pads | ~24 pads/yr at ~$6.70 ea | $804 |
| Squeegee blade sets | 2 sets/yr · 341-0113/0114 | $778 |
| Battery set (year 3) | 2 × 162-0042 AGM | $1,001 |
| Misc wear parts | Valves, hoses, casters as needed | $150 |
| 5-year total | ≈ $117/month all-in | $7,028 |
Estimates assume ~15 hrs/week of use on smooth concrete. Defects in non-wear parts are covered by the 5-year parts warranty — this table is the honest wear-and-tear picture competitors leave out.
One size down, this machine, one size up — same 5-year warranty and same-day parts support across the whole X-series ladder.
X15B · 15"
|
This machine
X20BT · 20" traction
|
X26BT · 26" traction
|
|
|---|---|---|---|
| Price | $4,357 | $4,295 | $6,595 |
| Cleaning path | 15 in380 mm | 20 in500 mm | 26 in660 mm |
| Coverage | 16,100 ft²/hr1,500 m²/hr | 24,200 ft²/hr2,250 m²/hr | 30,100 ft²/hr2,800 m²/hr |
| Solution tank | 6.6 gal25 L | 15 gal60 L | 21 gal80 L |
| Drive system | Pad assist | Traction drive | Traction drive |
| Weight | 240 lbs109 kg | 286 lbs130 kg | 386 lbs175 kg |
| View | Viewing now | View |
Replaced two mop crews on our gym floors. The traction drive matters more than we expected on the long hallway runs — operators aren't pushing 286 lbs, the machine is.
Bought it because they stock every part. Squeegee blades showed up next day when we finally wore the first set out. That's the whole reason to buy from these folks.
Simple enough that our rotating volunteers can run it after one walkthrough. Wish the recovery tank drained a little faster, but the manual actually covers how to speed it up.
Hosted here, on-domain — not an off-site PDF viewer. Everything the operator and the person signing the PO needs.
